Iec 62196 Mode 1 Ev Charging Box 16A 3.5kw Level 2 Type 2 Portable

Mode1 Ev Charging 16A 3.5kw EV Charger Level 2 EV Charger Type2 Portable Ev Charger electric vehicle car

All The Charger with test with follwing funtions to ensure the charger in perfect performance:

Withstand voltage insulation test - start high voltage machine test
Charging preparation -- measuring input voltage
Charging connection confirmation - measuring resistance
Ready to charge - measure current
Ready to charge - measuring frequency
Start up and charging stage - measure the output voltage
Start up and charging phase - measuring output current
Normal charge end test - measure output voltage
CP Disconnection Test: measure the output voltage after resuming charging
CP ground test - measure output voltage
Input overvoltage protection - measure output voltage
Input overvoltage protection - automatic recovery function, measuring output voltage
Input undervoltage protection - measure output voltage
Input undervoltage protection - automatic recovery function, measuring output voltage
Leakage protection - measuring output voltage
Overcurrent protection - measuring output current
Over current protection - automatic recovery function, measuring output current

Product specifications:

PLUG CAN BE CUSTOMIZED

ACCORDING TO YOUR REQUEST

How to start charging

1. Carefully check the MAX AC charging current & MAX AC charging power (KW) of your E-vehicle. (Ensure the Charger’s plug matches the outlet you want to use)

2. Firmly insert the wall side plug into the wall socket.
3. Change the charging current by pressing the button.
4. Put the charginig plug into the vechicle
How to stop charging
1. Disconnect the power plug from the wall socket.
2. Disconnect the Type1 plug from the vehicle.
