Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket
Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket
Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket
Contact Now

Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket

Minimum Order Quantity : 20 Price : negotiation
Delivery Time : 8-10days Payment Terms : L/C,D/A,D/P,T/T
Supply Ability : 500000 PIECE PER MONTH
Place of Origin: CHINA Brand Name: EVCOME
Certification: CE/TUV/ROHS/FCC Model Number: SHYR-A07

Detail Information
Type: Type 1 To Type 2 EV Charger Connector Place Of Origin: Guangdong, China: CHINA
Model Number: SHYR-A07 Brand Name: Evcome
Product Name: Type 1 To Type 2 Adapter Rated Voltage: AC 250V
Rated Current: 32A Insulation Resistance: >1000MΩ(DC 500V)
Withstand Voltage: 2000V / 5s Contact Resistance: 0.5mΩ Max
Terminal Temperature Rise: <50K Operating Temperature: -30°C~+50°C
Impact Insertion Force: 45N<F<80F Protection Degree: IP55
High Light:

iec 62196 type 2 socket

,

ev charging socket type 2

,

type 2 electric vehicle socket

Product Description

New Ev Charging Evse Type 1 To Type 2 Ev Socket Adapter
Main features:
Meet IEC 62196-2
Nice appearance, Support Back installation
Contact with drainage structure ,improve safety performance
Inner Core:Thermoplastic
Case Material: Thermoplastic,Flame Retardant Grade UL94 V-0.Terminal Material: Copper Alloy , Silver Plated Surface
Mechanical Life no-load plug in/pull out ＞5000 times
Superior Protection Performance ,Protection Level Up to IP67 (Inside the Product)
Safety pins material insulated head design to prevent accidental direct contact with employee
Item
Type 1 to Type 2 EV Adapter
Type 1 to Tesla EV Adapter
Type 2 to Type 1 EV Adapter
Standard
IEC 62196-2
IEC 62196-2
IEC 62196-2
Product Model
KW-T1-T2
KW-T1-TE
KW-T2-T1
Rated Operating Current
32A
60A
32A
Operation Voltage
AC 250V
AC 250V
AC 250V
Insulation Resistance
＞1000MΩ(DC 500V)
＞5MΩ(DC 500V)
＞1000MΩ(DC 500V)
Withstand Voltage
2000V / 5s
2000VAC /1min
2000V / 5s
Contact Resistance
0.5mΩ Max
0.5mΩ Max
0.5mΩ Max
Terminal Temperature Rise
＜50K
＜50K
＜50K
Operating Temperature
-30°C~+50°C
-30°C~+50°C
-30°C~+50°C
Impact Insertion Force
45N
45N
45N
Mechanical Life
> 5000 times
> 5000 times
> 5000 times
Protection Degree
IP55
IP55
IP55
Flame Retardant Grade
UL94 V-0
UL94 V-0
UL94 V-0
Certification
CE Approved
CE Approved
CE Approved



32A Type1 to Type2 EV adapter

One end is SEE J1772 Type 1 socket side

Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket 0

one end is IEC 62196 Type 2 vehicle side

Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket 1

Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket 2Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket 3

Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket 4

Iec 62196 Type 1 To Type 2 Ev Socket Adapter Electric Vehicle Charging Socket 5
